Chapter 2 Installing the Rack Mount Shelves
Installing the Shelves
38
8 Install the clamp strips (see
Position a front shelf clamp (PN 215812) at the front of the front
a
left rack rail, with the bottom of the clamp approximately 15.5
inches (394 millimeters) above the bottom of the rack mount
shelf.
The top of the front shelf clamp must be no more than
Caution:
22.75 in. (580 mm) above the bottom of the rack mount
shelf.
Position a clamp strip (PN 217405) behind the front left rack rail,
b
aligning it with the front shelf clamp.
Insert a screw (PN YS42064) through the upper hole in the front
c
shelf clamp, through the rack rail, and into the upper hole in the
clamp strip.
Insert a screw (PN YS42064) through the bottom hole in the front
d
shelf clamp, through the rack rail, and into the bottom hole in the
clamp strip.
Repeat steps 8a
e
clamp strip on the right rack rail.
ATL StackLink™ Installation Instructions
figure 27):
through 8d to install the front shelf clamp and
