Installing the Carriage/Counterweight Assembly
6 Secure the bottom mounting tray assembly to the rack, using the
screws (PN YS42011) and washers (PN YS40404) provided in the
StackLink kit (see
If the rack has widely spaced mounting holes, it may not
Note:
be possible to use all four screws to secure the rear flanges.
If this is the case, one screw per side at the rear is
acceptable.
7 Fully tighten the six screws and washers securing the rear support
arms to the sides of the bottom mounting tray.
Now that the top and bottom mounting trays are installed, install the
carriage/counterweight assembly on the vertical shuttle assembly (see
figure
7):
1 Slide the counterweight onto the bottom of the vertical shuttle
assembly, engaging the guide wheels of the counterweight with the
vertical rails.
ATL StackLink™ Installation Instructions
Chapter 1 Installing the StackLink
Installing the Carriage/Counterweight Assembly
figure
6).
1
11
