Verifying That You Have the Required Tools
The following tools are required to install the rack mount kit:
•
8 mm open end wrench
•
2.5 mm socket driver (preferably ball headed)
•
Flat blade screwdriver
•
Tape measure
Assembling the Rack Mount Shelves
To assemble the rack mount shelves:
1 Measure the distance between the inside surfaces of the front and
rear rack rails, then find the corresponding rack depth in
2 Assemble the left shelf:
Refer to the
a
Left Shelf/Shelf Extender
determine which shelf extender to combine with the left
universal shelf.
Insert the posts on the left universal shelf through the shelf
b
extender slots identified in the
The slots in the shelf extenders are identified as shown in
figure
20.
Use the M5 nuts (PN 41998) and M5 washers (PN YS40403)
c
provided in the rack mount kit to fasten the left shelf and shelf
extender together (see
Tighten the nuts to finger-tightness only; you need to be
Note:
able to retract and extend the assembled shelves slightly.
3 Assemble the right shelf in the same manner, referring to the
column of
table
Shelf
ATL StackLink™ Installation Instructions
Chapter 2 Installing the Rack Mount Shelves
column of
Left Shelf/Slots
figure
21).
5.
Installing the Shelves
2
2
table
5.
table 5
to
column of
table
5.
Right
31
