Chapter 3 Installing the Libraries

Installing the Safety Blanking Panels

Installing the Safety Blanking Panels
54
5 Repeat steps
1
through
Do not install a drive in drive bay 3. This drive bay is
Caution:
used only if a sixth drive is installed.
Do not attempt to install a sixth drive in the
Caution:
ATL M2500. This procedure requires specialized
software tools available only to Quantum-authorized
field service personnel. If a sixth drive is desired,
please call one of the following numbers to arrange for
a professional installation.
North America: 800-284-5101 or 949-725-2100
Europe: +44 1256 848748
Asia/Pacific: +61 (7) 3839 0988
Install safety blanking panels over all empty locations in the multiple
library stack:
The safety blanking panels are designed to prevent personal
Note:
injury or damage to the StackLink mechanism.
1 If the holes in the rack rails are square (untapped), insert caged nuts
into the holes where the front safety blanking panels will be installed.
2 To cover a 4U gap:
Install a 4U front safety blanking panel (PN 212579) at the front of
a
the rack, securing the panel with two screws (PN YS42011) and
washers (PN YS40404).
Install a 4U rear safety blanking panel (PN 212502) at the back of
b
the rack, securing the panel with two screws (PN YS41964).
ATL StackLink™ Installation Instructions
3
to install any additional tape drives.
3
