• Delimiter - an easily distinguishable double-blink that shows the overall status of
tests performed in EIM. The STAT LED color for delimiter is calculated from the
colors of other STAT LED blinks.
• Sufficient data for position computation.
• GPS S/N ratios are good (Table 4-2).
• GLONASS S/N ratios are good (Table 4-2).
• Oscillator's frequency offset is less than three ppm.
• Oscillator's Allan Variance is better than 2.7e-10.
• Continuous tracking time is more than 15 minutes.
In EIM, the STAT LED blinks seven times per cycle. Each blink could be orange, red,
or green.
• Orange – information for test unavailable.
• Green – receiver passed the test.
• Red – receiver failed the test.
1. To switch to EIM, press and quickly release (within one second) the FN key on the
2. Watch for the delimiter double-blink. With good receiver, antenna, and observation
•
•
•
3. To switch back to normal, press the FN key.

Downloading Files to a Computer

When your survey finishes, you can download your survey files to a computer
for storage, post-processing, or backup. Also, the Maxor memory holds a finite
www.javad.com
–Orange: at least one blink is orange.
–Red: no orange blink and at least one red blink.
–Green: all other cases.
Table 4-2. Signal-to-Noise (S/N) «Good» Ratios
GPS
GLONASS
MinPad.
conditions, all blinks should be green within 15 minutes of powering on.
Green - ok
Orange - wait
Red - some tests failed
CA/L1 P/L1
51 39
51 49
O P E R A T I O N

Downloading Files to a Computer

P/L2
39
40
