Battery LED

The color of the BATT LED indicates the level of internal battery charge in the
Maxor:
• Green – indicates greater than 90% charge.
• Orange – indicates an intermediate charge.
• Red – indicates less than 10% charge.
www.javad.com
Table 4-1. FN Key Functions and REC LED Status (Continued)
FN Key REC LED
When data recording is ON, and the FN key is...
Red
If FN key mode is «LED blink mode switch»
Green
Not pressed
If FN key mode is «Occupation mode switch»
Green
Orange
If FN key mode is «LED blink mode switch»
Orange
Pressed for < 1
second If FN key mode is «Occupation mode switch»
Orange
Pressed for 1–5 No light
Pressed for 5–8 Red
seconds
Pressed for > 8 No light
seconds
Status
No free memory; hardware problem
with data recording.
Data recording started (post-
processing occupation mode
undefined).
Data recording started (Kinematic
post-processing occupation mode).
Data recording started (Static post-
processing occupation mode).
Release to change information mode.
Release to toggle between Static and
Kinematic post-processing modes.
Release to stop data recording.
Release to turn serial port A baud rate
to 9600 bps.
No function (data recording still on).
