Using MinPad
This operation may require from fractions of a second to several minutes,
depending on the circumstances and the amount of internal memory.
FN Key
When data recording is OFF, and the FN key is...
Not pressed
Pressed for < 1
second
Pressed for 1–5
seconds
Pressed for 5–8
seconds
Pressed for > 8
seconds
4-4 Maxor User's Manual
Table 4-1. FN Key Functions and REC LED Status
REC LED
No light
Orange blink
Red
If FN key mode is «LED blink mode switch»
Orange
If FN key mode is «Occupation mode switch»
Orange
If FN key mode is «LED blink mode switch»
Green
If FN key mode is «Occupation mode switch»
Green
Red
No light
Status
No data recording.
Internal file system test in progress.
No free memory; hardware problem
with data recording.
Release to charge information mode.
No function.
Release to start data recording (post-
processing occupation mode
undefined).
Release to start recording (Kinematic
or Static post-processing occupation
mode).
Release to turn serial port A baud rate
to 9600 bps.
No function.
