S E T U P A N D S U R V E Y
3
Surveying with the Maxor
Notice: The reference geodetic coordinates you specify on this
tab relate to the antenna L1 phase center.
11. Select the Ports tab and set the following port parameters (Figure 3-12 on page 3-
15). Use serial port C for an internal PDL and GSM modem.
•
•
•
3-14 Maxor User's Manual
–Enable Averaged and enter the Averaged Span in seconds, then click Apply.
Click Tools->Reset receiver and wait until the specified interval (span)
completes. Examine the Base coordinates on the Base tab, they should correspond
to the coordinates obtained from the average. Click Refresh if the coordinates are
zeros.
Figure 3-11. Base Tab Configuration
Output drop-down list – select type and format of differential corrections.
Period (sec) – enter interval at which receiver will generate differential
corrections.
Baud rate drop-down list – select a baud rate (i.e., the rate at which differential
messages will be transmitted from receiver to modem).
