S E T U P A N D S U R V E Y
3
Surveying with the Maxor
After the survey completes, data the receivers collect can be downloaded onto a
computer and processed using post-processing software (for example,
Ensemble).
The procedure that follows describes the steps the operator should take to
perform a Static Survey using MinPad.
Connect your receiver and computer. See "Connecting the Maxor and a
1.
Computer" on page 2-8 for this procedure.
Open PCView, click Configuration->Receiver->MinPad and specify the
2.
following parameters, then click Apply (Figure 3-5):
•
•
•
•
Click the Advanced tab and then the Multipath tab, set the following
3.
parameters, then click Apply (Figure 3-6):
•
•
3-8 Maxor User's Manual
Recording Interval – 15 seconds
Elevation Mask Angle – 15 degrees
File Name Prefix – last 3 digits of receiver serial number
LED blink mode switch – enable to start and stop static data recording
using the FN key
Figure 3-5. Configuration->Receiver->MinPad
Code Multipath Reduction – enable
Carrier Multipath Reduction – enable
