Program Tab Settings - Javad Maxor User Manual

O P E R A T I O N
4
Loading New Firmware
Select the Program tab and set the Capture Method to Soft Break Capture
13.
(recommended) (Figure 4-18).
Browse for and select the Power board's RAM file (Figure 4-18).
14.
Click Load and wait until 100% of the power board file loads into your
15.
receiver.
Notice: If you selected an incorrect RAM file, an error message
displays at the bottom of the dialog box. Reselect the
correct file.
Click File->Exit.
16.
Clear the receiver's NVRAM (see"Clearing the NVRAM" on page 4-14)
17.
and update the almanac ("Collecting Almanacs" on page 2-34) after loading
new firmware.
4-20 Maxor User's Manual
Figure 4-18. Program Tab Settings
www.javad.com
