C O N F I G U R A T I O N
2
Connecting the Maxor and a Computer
Continue with Step 1 in "Establishing a PCView Connection" on page 2-10.
3.

Establishing a PCView Connection

PCView is a personal computer software used to manage the various functions
of your receiver. The full range of PCView configuration and function is outside
the scope of this manual. For more information on any of the procedures in this
section or on PCView, refer to the PCView User's Manual available on the JNS
website.
Once the receiver and a computer are connected, start PCView on your
1.
computer. The PCView main screen displays (Figure 2-9).
Notice that the lower-left hand corner shows the receiver status as
"Disconnected".
On the Connection Parameters dialog box, select the following parameters
2.
and click Connect:
•
2-10 Maxor User's Manual
Figure 2-9. PCView Main Window
For Bluetooth or RS-232 connections (Figure 2-10)
–Set the Connection mode (Direct).
–Set the port for your computer (typically COM1, COM2 for RS232 connection
and COM3, COM4, etc. for Bluetooth connection) from the Port drop-down list.
–Set the communication rate between the receiver and the computer (usually
115200) from the Baud rate drop-down list.
