12.
The Identification screen supplies current information concerning firmware
version, serial number, frequency, and power of the radio modem.
13.
Channel Select:
–Manual
–Channel TX RX
Modulation Type
Digisquelch
Forward Error Correction
Scrambling
Local Address
Channel Select:
–Manual
–Channel TX RX
www.javad.com
On the Identification tab, type Owner information (Figure 2-30).
Figure 2-30. PDL Identification Tab
Click the Radio Link tab and set the following parameters depending on the
link rate selected (Table 2-3 and Figure 2-31):
Table 2-3. Parameters for Selected Link Rate
Controls
9600
enable
set channel and frequency as
desired
GMSK
High
disable
enable
0
enable
set channel and frequency as
desired
C O N F I G U R A T I O N
Radio Configuration
Link Rate
19200
enable
set channel and frequency as
desired
4-Level-FSK
High
enable
enable
0
enable
set channel and frequency as
desired
Maxor User's Manual 2-25
