Marant+ Antenna Offset Measurements - Javad Maxor User Manual

MarAnt+ antenna offsets are shown in Figure 3-2; Offset measurements for this
antenna is given in Table 3-2.
3.
4.
www.javad.com
Figure 3-2. MarAnt+ Antenna Offset Measurements
Table 3-2. Antenna Offset Measurements
Antenna Radius
MarAnt+ SHMM1
69 mm
0.226 ft
Record the antenna height, point name, and start time in the field notes.
Attach the flexible RF cable from the external antenna to the antenna
connector on the bottom panel of the Maxor.
A, Vertical Offset
SHMM2 54.3 mm (L1)
89.7 mm 60.5 mm (L2)
0.294 ft
S E T U P A N D S U R V E Y
Maxor Receiver Setup
C, Slant Offset
26.8 mm (L1)
33.0 mm (L2)
Maxor User's Manual 3-5
