Warning: Before connecting the external power source and the receiver,
make sure that the power source matches the receiver's voltage
and current requirements.
Notice: When the receiver uses an external battery as the primary
power source, make sure that the charger mode is set to
Off. Otherwise, the external battery will also charge the
internal batteries, causing operation time to decrease.
See "Power Management" on page 2-4 for more
information on setting the charger mode.

Battery Charger

The same charger used to charge the internal batteries can be used as an external
power supply for the receiver. The charger is provided with the standard
receiver package.
To use power from the battery charger, connect the equipment as follows
(Figure 2-1 on page 2-4):
• Plug the Receiver-to-SAE cable's 5-pin connector (p/n 14-008016-03) into
the power port of the receiver (labeled PWR).
• Connect the opposite end of this cable with the battery charger's SAE
connector.
• Plug the appropriate end of the power supply-to-outlet cable into the battery
charger.
• Plug the other end of this cable into an AC outlet.
• Press and hold the Reset key for about one second to ensure that the receiver
is in Normal mode for accepting power.
• Turn on the receiver by pressing and holding the green power key for about
0.5 seconds.
