S E T U P A N D S U R V E Y
3
Maxor Receiver Setup
Turn on the Maxor and continue with step 3 on page 3-3.
5.
The Maxor antenna default is set to Auto, allowing the receiver to detect
automatically the available antenna (whether internal or external). If you have
changed this setting, or the receiver does not detect the external antenna, use the
procedure below to set the External Antenna detection option.
Connect your receiver and computer. See "Connecting the Maxor and a
1.
Computer" on page 2-8 for this procedure.
Start PCView.
2.
Click on Configuration->Receiver (Figure 3-3).
3.
On the General tab, select the External Antenna option (Figure 3-4).
4.
Click Apply, then Refresh to update the displayed tab with the new setting.
5.
Click File->Disconnect, then File->Exit.
6.
3-6 Maxor User's Manual
Figure 3-3. Configuration->Receiver
Figure 3-4. Select External Antenna Option
