C O N F I G U R A T I O N
2
Bluetooth Module Configuration
Run the Bluetooth module configuration program (Btconf.exe) (Figure 2-
3.
38).
Notice that the lower left corner shows a "Disconnected" status for the
computer and Bluetooth module.
For BTCONF version and copyright information, click the About button.
From the drop-down list in the upper left corner, select the computer serial
4.
port used for communication (Figure 2-39).
Click Connect to connect the computer and Bluetooth module (Figure 2-
5.
39).
Once the receiver and computer connect through BTCONF, the Identification
tab (Figure 2-40) displays the following information:
•
•
•
2-32 Maxor User's Manual
Figure 2-38. Bluetooth Module Configuration Main Screen
Figure 2-39. Select Communication Port and Click Connect
Bluetooth name – the name of the Bluetooth module, set in the Parameters
tab.
Bluetooth address – the unique electronic address for your Bluetooth
module.
Firmware base.
