8.
9.
10.
Notice: If you selected an incorrect RAM or Flash file, an error
message displays at the bottom of the dialog box.
Reselect the correct file.
11.
12.
www.javad.com
Select the Program tab and set the Capture Method to Soft Break Capture
(recommended) (Figure 4-16).
Figure 4-16. Program Tab Settings
Browse for and select the receiver board's RAM file and Flash file
(Figure 4-16).
Click Load and wait until 100% of the files load into your receiver.
Select the Device tab and set the Device Type as Receiver's Power Board
(Figure 4-17).
Click Get from Device for device information (Figure 4-17).
Figure 4-17. Set Device Type
O P E R A T I O N
Loading New Firmware
Maxor User's Manual 4-19
