The Maxor and external device connection procedure varies slightly depending
on the type of external device used. In general, the connection procedure is as
follows:
Notice: Refer to your Bluetooth-enabled external device
documentation for more detailed connection information.
1.
2.
3.
4.
If you cannot establish a connection, check that the receiver's slot three is
enabled.
1.
2.
3.

Establishing an RS-232 Cable Connection

1.
2.
3.

Establishing a USB Cable Connection

Make sure the computer has Javad's USB driver installed (available from http://
javad.com/jns/downloads/freesoft/jns_usb.zip) before continuing.
1.
2.
www.javad.com
Turn on a Bluetooth-enabled external device and your receiver. The default
external device mode is Master; the receiver's Bluetooth module mode is
Slave.
Instruct the external device (Master) to search for the receiver (Slave).
Once the Master device detects the receiver, use the procedure described in
the external device's documentation to connect it with the receiver.
Once connected, continue with Step 1 in "Establishing a PCView
Connection" on page 2-10.
Connect your receiver and a computer using an RS232 cable (see
"Establishing an RS-232 Cable Connection" on page 2-9).
Click Configuration->Receiver->General.
In the Turn on/off Slots area, ensure the Slot 3 (B) check box is enabled.
Using the RS232 cable, connect the serial port of your computer (usually
COM1) to the receiver's serial port A.
Press the power buttons on the receiver and computer to turn them on.
Continue with Step 1 in "Establishing a PCView Connection" on page 2-10.
Using the USB cable, connect the USB port on the receiver to a USB port on
the computer.
Press the power buttons on the receiver and computer to turn them on.
C O N F I G U R A T I O N
Connecting the Maxor and a Computer
Maxor User's Manual 2-9
