The manual mode screen will show RE002%% in response to each of these
commands. When finished, you should have seven responses in the manual
mode window's reply panel.
4.
How to configure a GSM radio modem with FieldView
Refer to the FieldView User's Manual for how to accomplish this task.

Bluetooth Module Configuration

Use BTCONF, the Bluetooth module's configuration program, and your
computer to:
• access the Bluetooth wireless technology module
• configure the Bluetooth module
• check or change the module's configuration
To access the Bluetooth wireless technology module, first download and install
BTCONF, then connect your computer and the receiver and run the
configuration program.
1.
2.
To uninstall, or remove, BTCONF, delete any applicable BTCONF directories
or folders, and any BTCONF shortcuts.
Once you have BTCONF available, follow these steps to configure the
Bluetooth module.
1.
2.
www.javad.com
%% set,/par/modem/c/ mode,slave – for the receiver configured as a base.
Now, the receiver is completely ready for field operation. Just switch the
receiver on when in filed. The receiver will automatically start working with
the GSM modem.
Create or locate the following folder:
C:\Program Files\JNS\BTCONF
Download btconf.zip from the JNS website and unzip it into the BTCONF
folder. This file contains Btconf.exe, the executable file for the Bluetooth
module configuration program.
Using the RS232 cable, connect the serial port of your computer to the
receiver's serial port A.
Press the power buttons on the receiver and computer to turn them on.
C O N F I G U R A T I O N

Bluetooth Module Configuration

Maxor User's Manual 2-31
