I N T R O D U C T I O N
1

Maxor Accessory Kit

• Multipath reduction
• Wide area augmentation system (WAAS)
• Adjustable phase locked loop (PLL) and delay lock loop (DLL) parameters
• Dual-frequency static, kinematic, real-time kinematic (RTK), and differential
GPS (DGPS) survey modes
• Auto data logging
• Setting different mask angles
• Setting different survey parameters
• Static or dynamic modes

Maxor Accessory Kit

Although the Maxor can be supplied with a number of different accessories, this
manual refers to the standard kit. For more information about different
accessories available, please contact your local Javad dealer or visit the
accessories section of the JNS website:
(http://www.javad.com/cgi-bin/WebShop/cgi?Action=DrawAccessoriesList).
Unpack the kit contents and check all the items thoroughly. If any item included
is damaged or missing, get in touch with your local dealer as quickly as
possible. The contents of the standard accessory kit contain:

• Cables

• Software
Cables
Standard Maxor accessories include the following cables:
• Receiver-to-computer RS232 serial cable (p/n 14-008005-02)
• Receiver-to-SAE power cable (p/n 14-008016-03)
• SAE-to-SAE cable extension (p/n 14-008022-01)
• USB cable
• Power supply with SAE connector and
power/charger cable (p/n 22-530101-01)
1.Only supplied for the Maxor with the USB option enabled.
1-6 Maxor User's Manual
1
(p/n 14-508031-01)
