Javad Maxor User Manual page 127

www.javad.com
Table B-1. Receiver Specifications (Continued)
Component
Ambiguity initialize
Baseline Length
Initialize time
Output interval for CMR/
RTCM
Elevation
Solution mode
Process interval
Latency
Raw Data Logging
Status
Results
Ambiguity fixing level
PPS Output (optional)
Number of PPS ports
Edge
Period
Offset
Reference time
Details
OTF (L1, L1/L2)
Up to 50km in the morning and evening. Up to 32
km at noon.
5 seconds to 10 min depending on the base line
length and multipath conditions
1Hz standard; 5, 10, 20Hz optional
0 to 90 degrees (independent of data logging)
Delay (synchronization)
Extrapolation (not synchronized)
1Hz standard; 5, 10, 20Hz optional
Delay mode - 20 msec to 20 sec (depends on latency
which receives corrections data from base receiver)
Extrapolation - 20 to 30 msec
The receiver can record raw data at another interval
during RTK operation
Fix, Float, DOP, Data Link Status, Modem Latency,
Common satellites, Percentage of fixing
RTK coordinates, HRMS, VRMS, Covariance
Matrix
Selectable thresholds Low: 95%; Medium: 99.5%;
High: 99.9%
1
Rise, Fall
10 to 1000000000 ms
-500000000 to 500000000 msec
-500000 to 500000 nsec
GPS, GLONASS, UTC (USNO), UTC (SU)
A P P E N D I X
Specifications
Maxor User's Manual B-7
