Codec Tieline ViA User Manual page 98

98 ViA User Manual v3
By default, return audio from the first audio stream is routed to analog OUTPUT 1 (decoder 1).
Return audio from the second audio stream is routed to OUTPUT 2 (decoder 2).
PPM Meters for 3 x Mono Peer-to-Peer Programs
The codec is capable of creating three independent mono peer-to-peer connections simultaneously.
By default, input 1 is routed to encoder 1, input 2 is routed to encoder 2, and input 3 is routed to
encoder 3.
When all 3 audio streams are connected, the codec will display a mix of all 3 outgoing streams on
the LEFT PPM. The sum of all 3 mono return audio channels is displayed on the RETURN PPM.
The left hand Connections screen PPM meters display outgoing program audio on the SEND PPM
and return audio on the RETURN PPM for all three connections.
PPMs on the Connections screen
© Tieline Research Pty. Ltd. 2020
