Codec Tieline ViA User Manual page 318

318 ViA User Manual v3
2. This audio stream connection in the wizard will allow the codec to dial. Enter the connection
name in the text box, then click Next
3. Configure the transport settings for the connection, then click Next.
Important Note: See
and see
4. Configure destination codec dialing and encoding settings:
For IP connections configure the IP address, ports, and then specify which streaming
interface is used to dial this connection, e.g. Primary (port LAN1) or Secondary (port
LAN2). Note: By default Any will select LAN1 if it is available and LAN2 if it is
unavailable.
If TieLink Contact List dialing is configured:
1. Click the Address Book
RS232 Data Configuration
Enabling Relays and RS232 Data
Address Book.
for detailed information on RS232 data
for more information on relay operations.
button to select a contact to dial from the TieLink
© Tieline Research Pty. Ltd. 2020
