USB Cellular Modem Indications
Symbol
1 No symbol
2
3
4
Connecting using a Cellular Module
1. Turn the codec off and insert a cellular module into the module slot.
2. Power up the codec and press the HOME
Settings
module menus and details.
Important Notes:
· Sometimes a cellular network will be detected and a module will connect automatically
after it is inserted. Tieline recommends always using the Overwrite APN (Access
Point Number) menu setting and entering the correct APN for your Telco. This ensures
use of the correct data APN. It is usually simple to search the internet for the correct
APNs used by each Telco. See
· It may be necessary to enter a SIM PIN if the codec cannot connect automatically to
the network.
· Cellular radio transmissions can be turned off without removing the module. Select
Settings
Enable Radio [OFF]
© Tieline Research Pty. Ltd. 2020
Description of Status
· A cellular modem is not attached to the codec.
· A modem is attached but not ready yet; it can take up to a minute for
the modem to be detected.
· The modem has a SIM card issue (locked or not present).
· The modem is not supported by the codec.
Each USB port is identified by the number 1 or 2 in the top-left corner of
the symbol.
A cellular modem is attached to the codec but there is an error. Check
that:
· The SIM card does not have a PIN code enabled.
· The modem has data enabled.
· The modem is compatible with the network to which you are
attempting to connect.
The cellular modem is connected to the network and signal strength is
displayed. Note: when first attached the symbol is greyed out while the
modem is connecting to the cellular network. It will remain greyed out if:
· Data is not enabled.
· No APN is selected and the modem doesn't contain a correct APN
setting from a factory default or previous connection.
· An incorrect APN is selected. When using different SIMs they may
require different APNs, even if they are from the same Telco.
· The correct APN is selected but data has run out.
· A custom APN has been added but either the APN info, or the
Authentication Type, is incorrect.
> Transport Interfaces > Cellular
> Transport Interfaces > Cellular
button to return to the Home screen, then tap
> Cellular Module 1 / 2 to view cellular
Adding Access Points and a SIM PIN
ViA User Manual v3
for more details.
> Cellular Module 1 / 2 >
