118 ViA User Manual v3
6. AES3 settings are confirmed in the Input Type field on the screen.
Important Note: There is a maximum of 6dB of additional gain available when adjusting
an AES input source.
AES42 Digital Microphone Input
VOLTAGE WARNING: DO NOT attach non-digital microphones or an AES3 source to input
1 when AES42 input mode is selected, or equipment may be damaged by high voltages. As
a safety measure, by default the codec will reboot and configure input 1 for an analog
microphone after an AES42 mic has been used. This default setting and AES42 warning
settings can be adjusted. See
Select AES42 as the Input Type for INPUT 1 to attach an AES42 digital microphone. The codec
supports mode 1 synchronization and if the mic sample rate is asynchronous to the codec sample
rate, a sample rate converter is used to convert between them. In AES42 mode INPUT 1 supplies
the 10V power required to operate mode 1 digital microphones. It also supports the remote control of
features such as pre-attenuation and low-cut filters in AES42 microphones.
1. Press the HOME
2. Tap Inputs
3. Tap the Settings symbol
General Audio Settings
button to return to the Home screen and tap Audio
to adjust audio input configuration settings.
on INPUT 1.
for more information.
