Swap Cue and Input On/Off Buttons
Some broadcasters prefer TB/CUE button operation to be available using the ON/OFF button for
each input.
1. Press the HOME
2. Tap General
3. Tap to enable Swap Cue and Input On/Off Buttons.
4. In this mode the TB/CUE buttons on inputs 1-3 are illuminated. When an input ON/OFF
button is pressed the button illuminates red, and the TB/CUE button is not illuminated, to
indicate TB/CUE mode is in use.
Loopback Audio Test
Loopback Audio Test mode is used by the codec to perform an input/output loopback test of
audio. E.g. Input 1 is routed to analog Output 1, Input 2 is routed to Output 2. The test remains
active until it is disabled, or a connection is dialed or answered, or a new program is loaded.
1. Press the HOME
2. Tap General
3. Tap the On/Off button to toggle the Loopback Audio Test setting on and off.
The following table outlines the default matrix settings for how inputs are routed to analog outputs in
loopback audio test mode.
Inputs
1
2
3
Aux In Left
Aux in Right
button to return to the Home screen, then tap Audio
.
button to return to the Home screen, then tap Audio
.
Analog Output 1
.
.
Analog Output 2
