352 ViA User Manual v3
Important Notes for Rules:
· The codec has 4 physical CONTROL PORT GPIOs; 7 Tieline and WheatNet virtual
inputs (1-7); 64 Tieline virtual logic outputs; and, 64 virtual WheatNet logic outputs
(these allow Tieline WheatNet-IP enabled codecs to activate functions across a
WheatNet-IP network). See
· A non-WheatNet-IP Tieline codec can be configured to trigger a WheatNet LIO in a
Tieline WheatNet-IP codec.
· Tieline WheatNet-IP codecs require Wheatstone Razor firmware version 1.4.22 or later
to support WheatNet LIOs. In addition, the WheatNet-IP codec must have the WNet
Enable LIO checkbox selected in the Options panel of the HTML5 Toolbox Web-GUI.
· Relay reflection is not available for SIP and Multicast Client programs.
· Connection-related rules are not displayed in Answer only audio streams.
· Rules intended to activate dialing will not be valid in Answer only programs or audio
streams.
· For more details about rules see
4. Enter a Stream Name, then add a Caller ID and configure the codec to dial, answer or dial
and answer. Then click Next.
Note: The following example will display how to configure a dial and answer program. If you want the
codec to either dial or answer only, select the option and the wizard will automatically display
screens to allow you to configure the codec correctly. Please note that caller ID, dial routes and G3
profile or G3 channel information can not be used for SIP connections because Tieline session data
is replaced by SDP for SIP connections.
5. This audio stream connection in the wizard will allow the codec to dial. Enter the name of
the connection in the text box, then click Next.
Enabling Relays & RS232 Data
Creating Rules.
for more info.
