33.14 Configure 2 Mono Peer-to-Peer Dialing Connections

ViA is capable of sending a mono program mix to two separate codecs over different connections.
This requires the creation of a dialing program in ViA with two separate mono audio streams and
associated dialing connections.
Configure a 2 x Mono Peer-to-Peer Dialing Program
Important Notes:
1. Open the HTML5 Toolbox Web-GUI and click Connect in the Menu Bar, then select Program
Manager to launch the Program Manager panel.
2. Click the New Program button to open the wizard and:
· Click in the text box to name the new program.
· Select 2 x Mono Peer-to-Peer, or if you want to use an existing program as a template,
select this option.
· Click to select the Favorite check-box if you want to add the new program to the list of
favorites in the codec. See
· Click the Mix drop-down arrow to associate a custom matrix mix with the program if required,
then click Next.
ViA 2 x Mono Peer-to-Peer Dialing Configuration
· A program cannot be edited when it is loaded in the codec.
· You can lock a loaded custom program
program cannot be unloaded by a codec dialing in with a different type of program.
· Some drop-down menus and settings may be greyed out intentionally depending on
features available and the transport selected (e.g. IP or ISDN).
· It is possible to save audio stream or program settings at several points throughout
the program wizard and use default settings to save configuration time.
· Failover and SmartStream PLUS redundant streaming are not available with SIP or
sessionless IP connections.
· When dialing a multistream program to both G3 and G5 codecs, by default the
Audio Reference Level will be configured for the compatibility of the codec that
connects first. I.e. if you dial a G3 codec first then the G3 Audio Reference Level will
be configured for all connections.
Load, Connect and Manage Programs
in a codec to ensure the currently loaded
for more details.
