Audio Menu Panels
Headphones Panel
Feature
1 Headphone select buttons
2 Headphone crosspoint matrix
3 Change Mix
4 Save
5 Save as
6 Options menu
7 Send/Return balance slider
Description
Click to select and view a headphone mix and edit routing
Click to select and deselect audio crosspoints to customize
routing.
Click to select the default or Custom headphone mix to view
and edit. Options include Load, Delete and Rename a mix
Menu options available to undo any changes, reset the mix
to the loaded matrix in the Matrix Editor, or save a new mix.
Click to save as a new custom headphone mix
Click the Options menu to undo any changes, reset the mix
to the loaded matrix in the Matrix Editor, or save as a new
mix.
Click and drag to adjust the balance between outgoing and
incoming audio.
