14.4

Connecting over SIP

Important Notes:
1. SIP interfaces are disabled by default.
2. SIP1 is configured to use LAN1 by default, which is mapped to the Primary Via
3. SIP2 is configured to use Wi-Fi by default, which is mapped to the Tertiary Via
4. SIP1 and SIP2 each need to use a separate IP interface when connecting, e.g. LAN1
5. SIP1 and SIP2 can each make multiple SIP calls, e.g. two calls can be made over
6. The settings for SIP1 and SIP2 cannot be edited if the interface has been enabled.
7. Enter a public IP address in the Public IP menu if you want to dial over SIP from
8. It is not possible to renegotiate the connection bit rate over a SIP connection.
9. When connecting to a Tieline G3 codec using SIP you need to manually select the G3
Dialing SIP Connections
SIP can be used to make direct peer-to-peer or SIP account calls to IP codecs configured with
public IP addresses, or between two codecs over a LAN. Peer-to-peer SIP calls are often used to
connect to other brands of codecs and perform call and session management tasks.
To make a peer-to-peer SIP call between codecs we recommend both codecs use public IP
addresses. Find out the IP address of the codec being dialed and configure each codec with a
compatible algorithm and sample rate etc. If the remote codec has a private IP address then it
should be configured for port forwarding and should dial the public IP address at the studio.
To dial using a SIP account it is necessary to add a SIP account and register it to the codec. See
Configuring SIP Accounts
1. Press the HOME
2. Tap Menu
Note: Tap Load Program to load preconfigured custom programs. Default programs cannot
be locked in the codec. Save a program as a custom program if a program needs to be
locked.
© Tieline Research Pty. Ltd. 2020
interface by default.
interface by default.
or LAN2.
SIP1, or two calls can be made over SIP2.
behind a firewall. Then configure port forwarding to route traffic to the codec's local IP
address behind your firewall. Note: Do not enter a Public IP address if STUN is
configured. They cannot be used together because both will attempt to use a public IP
address over SIP. STUN settings are prioritized and used if both are configured.
audio reference level. From the Home screen navigate to Audio
Reference Level > Tieline G3. In addition, select the following on the G3 codec
prior to dialing.
· Select either a mono or stereo profile
· Select [Menu] > [Configuration] > [IP1 Setup] > [Session Type] > [SIP]
· Select [Menu] > [Configuration] > [IP1 Setup] > [Algorithm] > [G711/G722 or
MP2]
for more info.
button to return to the Home screen, then tap Connections
and then tap Default Programs to view default program connection options.
ViA User Manual v3
> General
