33.20 Load, Unload and Dial a Program

A program can be loaded, unloaded and edited using the Program Manager panel or the
Connections panel. Audio stream dialing settings can be edited without unloading a program,
even if other audio streams are concurrently connected. Please note: If you need to use an existing
program as a template for a new program, or add a custom matrix mix to a program, the Program
Manager panel must be used to create a program.
Load and Unload a Program
1. Open the HTML5 Toolbox Web-GUI and click Connect in the Menu Bar, then select
Connections to launch the Connections panel.
2. Select Programs and then click the drop-down arrow to select one of the programs in the
codec, then click Load.
© Tieline Research Pty. Ltd. 2020
· Ports are arbitrarily assigned when answering calls using SIP accounts. By default
the UDP audio port range used is from 5004 to 5054. This setting can be adjusted in
the SIP Interfaces panel in the HTML5 Toolbox web-GUI. Ensure your firewall has
the required TCP and UDP ports open if you are receiving multiple SIP calls.
· Remember to lock an answering program in a codec when answering multiple SIP
calls.
· Ensure the appropriate TCP and UDP audio ports are open in your firewall to allow
multiple SIP audio streams to connect. See
more information.
· Failover and SmartStream PLUS redundant streaming are not available with SIP
connections
ViA User Manual v3
Installing the Codec at the Studio
363
