146 ViA User Manual v3
i. See
TOUCH SCREEN.
ii. See
b. ISDN answering can be configured to suit:
· Hardware available in the codec, i.e. the number of B channels available.
· Expected dialing behaviors, e.g. if B channels should bond or not, and whether audio
streams need to use Route tags.
· The type of call being made, e.g. Tieline (with Tieline Session Data) versus non-Tieline
(sessionless calls).
To adjust answering configuration using the TOUCH SCREEN select Home screen > Settings
> Answering > ISDN Answering and see
information.
To configure answering settings with the HTML5 Toolbox Web-GUI see
Answering.
28.1

ISDN Module Settings

ISDN Module settings in the Transport Interfaces menu determine how an ISDN module operates
at a particular site. Other answering-related settings are available in the Transport menu via
Answering > [Select ISDN Config]. The codec displays ISDN line sync status in the Status Bar
at the top of the TOUCH SCREEN.
Symbol
1 No ISDN
Symbol
2
3
Configuring ViA ISDN Modules
To adjust ISDN module settings:
1. Press the HOME
2. Tap Transport Interfaces to expand the menu if it is not displayed, then tap ISDN Module
to configure module settings.
Configure ISDN Module Settings
Configuring ISDN Modules
Description of Status
No ISDN module is installed in the codec.
An ISDN module is installed in the codec and either:
· No ISDN line is attached to the codec, or
· ISDN line is attached but line sync hasn't been detected by the
module
An ISDN module is installed in the codec and line sync has been detected.
button to return to the Home screen and tap Settings
for more information about configuration using the
to adjust settings using the HTML5 Toolbox Web-GUI.
ISDN Answering Configuration for more
Configuring ISDN
.
