33.11 Configuring Input/Output Settings

Open the HTML5 Toolbox Web-GUI and click Inputs to display the Inputs panel.
Adjusting Audio Levels
To adjust input audio levels, click on the input slider and drag it to the desired input gain level.
Alternatively, click the arrows below a PPM meter to incrementally increase or decrease the input
level in 0.5dB steps. Input levels on the Input panel should be set to ensure audio peaks average at
the first yellow indications on the PPM meters, which represents nominal 0 VU at -18dBFS. Audio
levels should also be verified using the meters in the PPMs panel.
Important Notes:
· There is a maximum of 6dB of additional gain available when adjusting a digital input.
· Turn off all unused inputs to avoid additional noise in program audio.
Changing the Input PPM Meter Units from dBFS to dBU
It is also possible to switch the analog input PPM meter unit of measurement from dBFS
(default) to dBU:
1. Open the HTML5 Toolbox Web-GUI and click Settings in the Menu Bar, then click
2. Select Audio and then click Edit.
3. Click the Analog Inputs PPM Units drop-down menu and select dBU.
3. Click Save to change the setting.
Options to display the Options panel.
