Codec Tieline ViA User Manual page 115

2. Tap the On/Off button to enable and disable this feature.
Show AES42 Mic Input Warning Dialog
By default, an AES42 warning dialog is displayed when AES42 is selected as the Input Type on
input 1. This feature can be disabled if required:
1. Press the HOME
> Show AES42 Mic Input warning dialog.
2. Tap the On/Off button to enable and disable this feature.
Output AGC (Automatic Gain Control)
AGC is enabled by default on all outputs. AGC is independent of IGC (Intelligent Gain Control) on
each input.
AGC is triggered if mixed audio signals approach -2dBFS.This is to prevent hard clipping, which
would introduce excessive distortion when the summed input signals exceed the full-scale range.
AGC has a very fast reaction time and will decrease high audio levels by approximately 1dB every
few milliseconds, up to a maximum of 34 dB of attenuation. AGC tries to return levels to normal
once the output dips below -7dBFs. This will gradually increase the levels by approximately 1dB
after a predetermined time-frame measured in milliseconds. To enable or disable AGC:
1. Press the HOME
2. Tap General
3. Tap the On/Off button to toggle AGC on and off.
© Tieline Research Pty. Ltd. 2020
button to return to the Home screen, then tap Audio
button to return to the Home screen, then tap Audio
.
ViA User Manual v3
> General
.
115
