Important Note: When you decide to use an existing program as a template, the new
program inherits all the settings of the template program and you can adjust these
settings as required by continuing through the program wizard.
3. To configure new program level rules click the drop-down arrow and select the preferred
option from those available. Click the blue Plus symbol
Minus symbol
Important Notes for Rules:
· The codec has 4 physical CONTROL PORT GPIOs; 7 Tieline and WheatNet virtual
inputs (1-7); 64 Tieline virtual logic outputs; and, 64 virtual WheatNet logic outputs
(these allow Tieline WheatNet-IP enabled codecs to activate functions across a
WheatNet-IP network). See
· A non-WheatNet-IP Tieline codec can be configured to trigger a WheatNet LIO in a
Tieline WheatNet-IP codec.
· Tieline WheatNet-IP codecs require Wheatstone Razor firmware version 1.4.22 or later
to support WheatNet LIOs. In addition, the WheatNet-IP codec must have the WNet
Enable LIO checkbox selected in the Options panel of the HTML5 Toolbox Web-GUI.
· Relay reflection is not available for SIP and Multicast Client programs.
· Connection-related rules are not displayed in Answer only audio streams.
· Rules intended to activate dialing will not be valid in Answer only programs or audio
streams.
· For more details about rules see
4. Enter a Stream Name, then add a Caller ID and configure the codec to dial, answer or dial
and answer. Then click Next.
Note: The following example will display how to configure a dial and answer program. If you want the
codec to either dial or answer only, select the option and the wizard will automatically display
screens to allow you to configure the codec correctly. When answering multiple SIP connections,
answer routes can be used to create deterministic dialing, which routes audio from incoming calls
consistently to the same inputs and outputs. For more information please see
SIP Peer-to-Peer
© Tieline Research Pty. Ltd. 2020
to remove a rule.
Enabling Relays & RS232 Data
Programs. Please note that caller ID, dial routes and G3 profile or G3 channel
Creating Rules.
ViA User Manual v3
to add a new rule and click the
for more info.
Answering Multiple
