72
ViA User Manual v3
14.7
Connecting POTS
The following procedure will create a custom peer-to-peer POTS connection program using the
codec's TOUCH SCREEN. Attach a POTS line to the module installed in your codec. The codec
displays POTS line status in the Status Bar at the top of the TOUCH SCREEN.
Symbol
1
No POTS
Symbol
2
3
Important Notes:
· Configure the correct
G5 module for varying ring tones and line impedances in different countries.
· See
and maintaining reliable POTS connections.
· See
· See
answering calls from non-Tieline POTS codecs)
· See
· The Local and Remote line quality displayed for POTS Codec connections is related to
the actual POTS line quality at either end of the link. This reading affects the maximum
allowable bit rate when the codec is training and negotiating a connection.
· DO NOT connect the analog POTS module to a digital phone system. PERMANENT
DAMAGE MAY OCCUR!
1. Press the HOME
2. Tap Menu
Default programs cannot be locked in the codec. Save a program as a custom program if a
program needs to be locked.
3. Tap to select the preferred program connection option, e.g. Default Mono, and then tap
Done. Note: Tap Load Program to load preconfigured custom programs.
4. To adjust connection settings tap the Connection Settings
screen.
5. Tap Transport to adjust this setting if the current selection is IP.
Description of Status
No POTS module is installed in the codec.
A POTS module is installed in the codec but no POTS line is attached to
the codec
A POTS module is installed in the codec and line voltage has been detected
country setting
POTS Connection Tips and Precautions
POTS Module Settings
POTS Answering Configuration
Configuring POTS
for details on configuring codec connections via a computer.
button to return to the Home screen, then tap Connections
and then tap Default Programs to view program connection options. Note:
for connections over POTS to adjust the ViA POTS
for valuable information about setting up
for details on module settings.
for details on POTS answering settings (required for
.
symbol on the Connections
© Tieline Research Pty. Ltd. 2020
