Ethernet and VLAN Configuration Options
The codec features two physical Ethernet port interfaces (LAN1 and LAN2) and up to four additional
VLAN interfaces. VLAN interfaces have features similar to physical Ethernet interfaces. However,
your network administrator will need to configure VLAN support throughout your network for VLANs
to be supported in your codec. As an example, if only one physical Ethernet interface is available,
VLANs can be used to operate SmartStream PLUS or separate codec 'control' and 'streaming'
functions if required.
Following are a range of options which can be configured in the LAN menus. After completing
configuration tap Save in the top right-hand corner of the screen to apply the new settings.
Configure an IPv4 DHCP Address
By default the codec is configured for DHCP-assigned IP addresses. DHCP addresses are
automatically assigned and can change each time you connect to your Internet Service Provider, or
by a router on your local area network (LAN).
1. Press the HOME
2. Tap to select Transport Interfaces and then LAN1
be configured using the Toolbox HTML Web-GUI.
3. Tap Network Settings.
4. Tap IPv4 Configuration.
5. Tap to select DHCP.
© Tieline Research Pty. Ltd. 2020
button to return to the Home screen, then tap Settings
ViA User Manual v3
or LAN2 . Note: VLANs need to
