Options and Accessories

11 Options and Accessories

11.1 Communication Options

•
VLT
•
VLT
•
VLT
•
VLT
•
VLT
•
VLT
•
VLT
•
VLT
•
VLT
•
VLT

11.2 I/O, Feed-back and Safety Options

11.2.1 VLT
MCB 101
MCB 101 is used for extension of digital and analog inputs
and outputs of FC 301 and FC 302.
Fit MCB 101 into slot B in the VLT
11 11
Contents:
•
MCB 101 option module
•
Extended fixture for LCP
•
Terminal cover
MCB 101
General Purpose I/O
SW. ver. XX.XX
X30/ 1 2
Illustration 11.1 MCB 101 Option
152
®
PROFIBUS DP V1 MCA 101
®
DeviceNet MCA 104
®
CAN Open MCA 105
®
EtherCAT MCA 124
®
PROFIBUS Converter MCA 114
®
PROFINET MCA 120
®
EtherNet/IP MCA 121
®
Modbus TCP MCA 122
®
POWERLINK MCA 122
®
DeviceNet Converter MCA 194
®
General Purpose I/O Module
®
AutomationDrive.
FC Series
B slot
Code No. 130BXXXX
3 4 5 6 7 8 9
®
VLT AutomationDrive FC 301/FC 302 Design Guide, 0.25-75 kW
11.2.1.1 Galvanic Isolation in MCB 101
Digital/analog inputs are galvanically isolated from other
inputs/outputs on the MCB 101 and in the control card of
the frequency converter. Digital/analog outputs in the MCB
101 are galvanically isolated from other inputs/outputs on
the MCB 101, but not from these on the control card of
the frequency converter.
If the digital inputs 7, 8 or 9 are to be switched by use of
the internal 24 V power supply (terminal 9), establish
connection between terminals 1 and 5, see Illustration 11.2.
Control card (FC 100/200/300)
General Purpose
I/O option MCB 101
DIG IN
X30/
PLC
(PNP)
0V
PLC
(NPN)
10 11 12
24V DC
Illustration 11.2 Principle Diagram
MG33BF02 - Rev. 2013-12-20
CPU
0V
CPU
0V
DIG &
ANALOG
RIN=
OUT
5kohm
1 2 3 4 5 6 7 8
24V DC
0V
24V
24V
ANALOG
IN
RIN=
10kohm
9 10 11 12
0-10
VDC
0-10
VDC
