Table 109 LED description
LED
LINK
ACT
Interface cables and the connection methods
For more information about BSV interface cables and the connection methods, see
interface."

Serial interface module

•
MIM-2SAE
•
MIM-4SAE
•
MIM-8SAE
•
MIM-8ASE
•
MIM-16ASE

MIM-2SAE/MIM-4SAE/MIM-8SAE

Introduction
The MIM-2SAE/MIM-4SAE/MIM-8SAE
synchronous/asynchronous serial interface module. In terms of function, SAE modules are the same
as SA modules except that SAE modules support more protocols, for example, RS449, X.21, and
RS530.
Interface specifications
Table 110 Interface specifications
Item
Connector
Number of connectors
Interface standard and
operating mode
Minimum baud rate
(bps)
Description
•
Off: No link is present.
•
On: A link is present.
•
Off: No data is being received or transmitted.
•
Flashing: Data is being received and/or transmitted.
Synchronous
D28
2 (MIM-2SAE)
4 (MIM-4SAE)
8 (MIM-8SAE)
V.35, RS449, X.21,
V.24
RS530
DTE, DCE DTE, DCE
1200 1200
80
stands for 2/4/8-port
Asynchronous
RS-232
300
"BSV/BSE
enhanced high-speed
