NOTE:
When a V.24 cable is used, the baud rate of the FIC-SA in synchronous mode cannot exceed 64
Kbps.
Interface specifications
Table 180 Interface specifications
Item
Connector
Number of connectors
Interface standard and
operating mode
Min. baud rate(bps)
Max. baud rate(bps)
Cable
Supported service
Interface LEDs
Figure 148 FIC-2SAE panel
Synchronous
DB-28
2 (FIC-2SAE)
4 (FIC-4SAE)
8 (FIC-8SAE)
V.24 V.35, RS449, X.21, RS530
DTE, DCE DTE
1200 1200
64 k 4.096 M
•
V.24 (RS-232) DTE cable
•
V.24 (RS-232) DCE cable
•
V.35 DTE cable
•
V.35 DCE cable
•
X.21 DTE cable
•
X.21 DCE cable
•
RS449 DTE cable
•
RS449 DCE cable
•
RS530 DTE cable
•
RS530 DCE cable
•
DDN leased line
•
Terminal access service
132
Asynchronous
RS-232
DCE
300
2.048 M 115.2
•
Dialup through modem
•
Backup
•
Asynchronous leased line
•
Terminal access service
