Table 66 Description for the DMIM-24FSW/DMIM-24FSWP GE interface LEDs
LED status
Off
Steady green
Flashing green
Steady yellow
Flashing yellow
Table 67 Description for the DMIM-24FSW/DMIM-24FSWP fiber port LEDs
LED status
Off
Steady green
Flashing green
Steady yellow
The MIM-16FSWP and DMIM-24FSWP interface modules each also provide a PoE LED to indicate
the PoE status.
NOTE:
The two GE interfaces on the DMIM-24FSWP do not support PoE.
Interface cables and the connection methods
For more information about the Ethernet interface cables and the connection methods, see
interface."
For more information about transceiver modules, optical fibers, and the connection methods, see
"Fiber port."

DMIM-48FSW

Introduction
The 48-port Ethernet Layer 2 switching MIM interface module (DMIM-48FSW) can be installed on
the MSR 30 routers. Each DMIM-48FSW provides 46 ordinary 10/100 Mbps RJ-45 connector
interfaces and two 10/100/1000 Mbps RJ-45 connector copper ports. DMIM-48FSW is suitable for a
small enterprise network to serve as a switching and routing device, which can be directly connected
to PCs and network devices of the enterprise. DMIM-48FSW supports the following functions:
•
A transmission distance of 100 m (328.08 ft) when connected with a category-5 twisted pair
cable (crossover or straight-through cable).
•
Wire-speed forwarding between any ports when connected with a category-5 twisted pair cable
(crossover or straight-through cable).
Description
No link is present.
A gigabit link is present, but no data is being transmitted and received.
A gigabit link is present and data is being transmitted and received (ACT).
A 100 Mbps link is present, but no data is being transmitted and received.
A 100 Mbps link is present and data is being transmitted and received (ACT).
Description
No link is present.
A link is present, but no data is being transmitted and received.
A link is present and data is being transmitted and received (ACT).
Error prompt
50
"Ethernet
