MIM-16FSW/MIM-16FSWP/DMIM-24FSW/DMIM-24FSWP

Introduction
A router installed with MIM-16FSW/MIM-16FSWP/DMIM-24FSW/DMIM-24FSWP interface modules
can work as a switching/routing integrated device on a small-sized enterprise network to connect
PCs and network devices inside the network directly. MIM-16FSWP/DMIM-24FSWP can supply
power to PDs through PoE.
The interfaces provided on the MIM-16FSW and DMIM-24FSW module are as follows:
•
16 × 10/100 Mbps RJ-45 connector interfaces on the MIM-16FSW module
•
24 × 10/100 Mbps RJ-45 connector interfaces on the DMIM-24FSW module
•
2 × 10/100/1000 Mbps (gigabit) RJ-45 connector copper ports on the DMIM-24FSW module
•
2 × SFP fiber ports (Fiber ports and gigabit copper ports share the MAC layer) on the
DMIM-24FSW module
The interface modules support:
•
100 m (328.08 ft) of transmission distance over the category-5 twisted-pair cable
•
100 m (328.08 ft) of transmission distance between any interfaces over the category-5
twisted-pair cable
•
Operation at 100 Mbps and 10 Mbps, autosensing
•
Full duplex and half-duplex, with the former in common use
•
24FSW provides two Combo interfaces as shown in
effect.
Interface specifications
Table 64 Interface specifications
Item
Connector
Interface type
Number of
connectors
Cable type
Operating
mode
MIM-16FSW/MIM-16FSWP module
RJ-45
MDI/MDIX
16 No 100 Mbps RJ-45 connectors
Straight-through and crossover Ethernet
cable
10/100 Mbps autosensing
Full/half duplex
Table 64. By default, the copper ports take
DMIM-24FSW/DMIM-24FSWP module
RJ-45 + SFP fiber port
MDI/MDIX + SFP fiber port
•
24 × 100 Mbps RJ-45 connectors
•
2 × 1000 Mbps RJ-45 connectors
•
2 × SFP connectors
Straight-through and crossover Ethernet cable;
Fiber port supports SFP fiber module
•
24 × 100 Mbps copper port: 10/100 Mbps
autosensing
•
2 × gigabit copper port: 10/100/1000 Mbps
autosensing
•
2 × gigabit fiber port: gigabit SFP fiber port
