Table 35 LED description
LED
LINK
ACT
Interface cables and the connection methods
For more information about FXS/FXO interface cables and the connection methods, see
"ADSL/BS/FXS/FXO/AM/FCM

SIC-2FXS1FXO

Introduction
The 2-port analog subscriber circuit interface module and 1-port voice AT0 loop trunk interface
module (SIC-2FXS1FXO) serve to access and handle three channels of analog voice signals over
data communication networks. Two FXS interfaces and one FXO interface are available on a
SIC-2FXS1FXO module:
•
FXS interfaces are analog subscriber line interfaces that provide ordinary analog telephone and
fax access and also can connect AT0 loop trunks of exchanges.
•
FXO interfaces are loop trunk interfaces that provide access of common subscriber lines of
exchanges.
Interface specifications
Table 36 Interface specifications
Item
Connector type
Number of connectors
Interface standard
Cable type
Dial-up mode
Bandwidth
Description
•
Off: The link is idle.
•
On: The link is being occupied for call connection.
•
Off: The link is idle.
•
On: The link is being occupied for communication.
interface."
Description
RJ-11
2 FXS interfaces
1 FXO interface
•
Supports subscriber circuit interface (FXS), compliant with ITU Q.512
•
Supports loop trunk interface (FXO), compliant with ITU Q.552
•
Over-current and over-voltage protection compliant with ITU K.20
Telephone cable with ferrite core
Supports DTMF, compliant with GB3378, but does not support pulse dial-up.
300 Hz to 3400 Hz
