E1/T1 interface module

•

SIC-E1-F

•
SIC-2E1-F
•
SIC-EPRI
•
SIC-1EPRI
•
SIC-TPRI
•
SIC-T1-F
SIC-E1-F
Introduction
The 1-port fractional E1 interface module (SIC-E1-F) supports:
•
Transmission/Receiving and handling of E1 data streams
•
CE1 (channelized E1) access
•
Remote loopback and local loopback functions, facilitating fault test and location.
The major differences between a SIC-E1-F and a SIC-EPRI are:
•
The timeslots on an interface in FE1 mode on the SIC-E1-F can be bundled to form one
interface (namely, can be bundled into one channel, and the rate of the interface is n No 64
Kbps, where n ranges from 1 to 31.); however, you may bundle timeslots of a PRI interface on
the SIC-EPRI into up to 31 channel sets.
•
The SIC-E1-F does not support the PRI mode.
Interface specifications
Table 10 Interface specifications
Item
Connector type
Number of connectors
Interface standard
Interface rate
Cable type
Operating modes
Supported services
Description
D15
1
•
G.703
•
G.704
2.048 Mbps
75-ohm unbalanced coaxial cable (D15 to BNC)
•
E1
•
CE1
•
Backup
•
Terminal access
