Interface specifications
Table 182 Interface specifications
Item
Connector
Number of connectors
Interface standard and operating mode
Cable type
Min. baud rate (bps)
Max. baud rate (bps)
Service supported
Interface LEDs
Figure 151 FIC-8ASE panel
Figure 152 FIC-16ASE panel
The FIC-8ASE/FIC-16ASE has one LED for each port. These LEDs are located in the apertures
beneath the ports. When the LED is on, a link is present. When the LED is off, data is being
transmitted and/or received.
Interface cables and the connection methods
For more information about asynchronous serial port cables and the connection methods, see
"Asynchronous serial
FIC-8ASE
RJ-45
•
•
RS-232
•
•
•
300
115.2 k
•
•
•
•
ports."
134
8 (FIC-8ASE)
16 (FIC-16ASE)
AUX cable
Ethernet straight-through cable
FIC-8ASE/FIC-16ASE dumb terminal cable
Dialup through modem
Backup
Terminal access service
Asynchronous leased line
FIC-16ASE
