SIC-1ADSL-I

Introduction
The 1-port ADSL over ISDN interface module (SIC-1ADSL-I) uses the RJ-11 connector for the WAN
interface. It allows a LAN subscriber to connect to the DSLAM at the central office over a regular
analog subscriber line or telephone line. Thus, the subscriber can access the ATM/IP backbone or
the Internet to enjoy services such as high-speed data communication and video on demand (VoD).
The module transmits data in the high frequency band above 138 kHz. Therefore, it can provide
services on the same line without interfering with the ISDN service being provided on the same line.
It provides downlink rates in the range 32 kbps to 8 Mbps and uplink rates in the range 32 kbps to 1
Mbps.
The SIC-1ADSL-I interface module delivers these features:
•
Manual ADSL line activation and deactivation, providing a convenient fault location means
•
A G.992.1-compliant interface, autosensing
•
Trellis coding on ADSL interfaces, enhancing the stability of ADSL connection
Interface specifications
Table 30 Interface specifications
Item
Connector
Number of connectors
Interface rate
Interface standard
Interface rate
Interface cable
Supported services
Maximum received and sent
frame
Description
RJ-11
1
•
In ADSL full rate mode (ITU-T 992.1 G.DMT/ANSI T1.413):
8 Mbps (downlink rate)
1024 kbps (uplink rate)
•
In ADSL Lite mode (ITU-T 992.2 G.Lite):
64 kbps to 1 Mbps (downlink rate)
64 kbps to 512 kbps (uplink rate)
•
In ADSL2+ full rate mode (ITU-T 992.5):
24 Mbps (downlink rate)
1024 kbps (uplink rate)
•
ITU-T 992.1 G.DMT
•
ITU-T 992.2 G.Lite
•
ANSI T1.413 Issue 2
•
ITU-T 992.3
•
ITU-T 992.5
•
Downlink: 8 Mbps
•
Uplink: 1024 kbps
Regular telephone cable
ADSL over ISDN
1700 bytes
