- Page 1 H3C SecPath NSQM2AC1400 Power Module User Manual New H3C Technologies Co., Ltd. http://www.h3c.com.hk Document version: APW101-20170414...
- Page 2 Copyright © 2016-2017, New H3C Technologies Co., Ltd. and its licensors All rights reserved No part of this manual may be reproduced or transmitted in any form or by any means without prior written consent of New H3C Technologies Co., Ltd. Trademarks H3C,...
- Page 3 Obtaining documentation To access the most up-to-date H3C product documentation, go to the H3C website at http://www.h3c.com.hk To obtain information about installation, configuration, and maintenance, click http://www.h3c.com.hk/Technical_Documents To obtain software version information such as release notes, click http://www.h3c.com.hk/Software_Download Technical support service@h3c.com...
-
Page 4: Table Of Contents
Contents Overview ·················································· 1 Front panel ···································································· 2 Technical specifications ··················································· 3 LEDs ············································································ 4 Installing and removing the power module ······· 6 Installing the power module ··············································· 6 Removing the power module ············································· 8 Connecting and removing the power cord ···························· 8... -
Page 5: Overview
Overview The NSQM2AC1400 AC-input DC-output power module has the following features: • It has a protection mechanism against input undervoltage, output overvoltage, output short circuit, output overcurrent, and overtemperature. • It is hot swappable. You can install and remove the power module on an operating device when the power switch on the power module is turned off. -
Page 6: Front Panel
Front panel Figure 1 Front panel (1) Captive screw (2) Power switch (3) Status LEDs (4) Power cord retainer (5) AC power receptacle (6) Handle... -
Page 7: Technical Specifications
Technical specifications Table 1 Technical specifications Item Specifications Input voltage range 100 to 240 VAC @ 50/60 Hz Maximum output current 117 A • 1150 W at 110 VAC Maximum output power • 1400 W at 220 VAC 128 × 196 × 380 mm (5.04 × Dimensions (H ×... -
Page 8: Leds
LEDs CAUTION: • The power module restores operation automatically when the power output alarm, such as short circuit, overcurrent, or overtemperature, is cleared. The power module does not restore operation automatically when the output overvoltage alarm is cleared. To restore operation of the power module, perform the following steps: a. - Page 9 Status Description No power output. Green Normal power output. The power switch is off. OUTPUT A power output alarm, such as output short circuit, overcurrent, overvoltage, or overtemperature, has occurred. The power module has entered self-protection mode. No power input. Green The fan is operating correctly.
-
Page 10: Installing And Removing The Power Module
Installing and removing the power module CAUTION: Do not install the NSQM2AC1400 power module and other types of power modules on the same device. To avoid bodily injury and device damage, follow the procedures Figure 2 Figure 3, respectively, to install and remove the power module. - Page 11 Follow the forward inertia to push the power module into the chassis. To avoid damaging the power module and the connectors on the backplane, pull out and reinstall the power module in case of any misalignment. Figure 4 Installing the power module Use a Phillips screwdriver to fasten the captive screws on the power module.
-
Page 12: Removing The Power Module
Figure 5 Fastening the captive screws on the power module Removing the power module Wear an ESD wrist strap, and make sure the wrist strap makes good skin contact and is reliably grounded. Use a Phillips screwdriver to loosen the captive screws on the power module. - Page 13 The following describes the procedure for connecting a power cord. To remove a power cord, follow the inverse order. To connect the power cord: Use a Phillips screwdriver to remove the screws from the power cord retainer and remove the right part of the retainer. Connect the power cord to the power receptacle on the power module.
