Table 239 SIC-4G-LTE-M 4G antenna specifications
Item
Frequency scope
Voltage standing wave ratio
Input impedance
Gain
Polarization type
Maximum input power
Interface
Height
Weight
Color
Operating temperature
Installing a 4G antenna for the SIC-4G-LTE-M module
Unfold the antenna to 180º.
1.
Attach the antenna to the antenna port on the module. To avoid damage, do not use excessive
2.
force.
Fold the antenna to an angle of 90º so that the antenna is vertical to the ground or ceiling to
3.
achieve optimal coverage.
Connecting an antenna extension cable for the SIC-4G-LTE-M module
Fasten the SMA connector onto the antenna port on the module.
1.
Attach the magnetic cradle on the other end of the extension cable to the rack.
2.
Connecting a USB console cable for the SIC-4G-LTE-M module
The SIC-4G-LTE-M interface module has a mini USB port for debugging. To debug the module
through third-party software, use a USB console cable to connect the mini USB port on the module to
a peer device, typically a PC.
When the interface module is operating correctly, you do not need to connect a USB console cable.
Specifications
698 to 960 MHz
1.71 to 2.7 GHz
2.5
50 ohms
2 dBi
Vertical
5 W
TNC
21.4 cm (8.43 in)
50.5 g (1.78 oz)
Black
–40°C to +85°C (–40°F to +185°F)
