LED
1xRTT
EVDO
Antennas, interface cables, and the connection methods
For more information about antennas, interface cables, and the connection methods for the
SIC-3G-CDMA module, see
Installing a SIM module
CAUTION:
Make sure the beveled corner of the SIM module fits into the beveled corner of the SIM socket.
To installing a SIM module:
Open the SIM module socket in the direction marked OPEN so the holder projects upwards.
1.
Insert the SIM module into the SIM module socket along the guide rails.
2.
Close the SIM module socket in the direction marked LOCK to lock the card in position.
3.
Execute the display cellular [ interface-number ] command after the router is started. When
4.
"SIM Status = OK" appears in the output information, the SIM module is identified.

SIC-3G-GSM

Introduction
The SIC-3G-GSM module provides access to 3G networks. It supports the following features:
•
GPRS
•
EDGE
•
UMTS
•
HSDPA
Interface specifications
Table 50 Interface specifications
Item
Connector type
Number of connectors
Interface standard
Description
•
Steady yellow indicates the service is valid.
•
Off indicates no service.
•
Steady yellow indicates the service is valid.
•
Off indicates no service.
"3G interface."
Description
TNC: For connecting an antenna and accessing WLANs.
RJ-45: For connecting to a third-party WLAN debugging and testing software
such as CAIT of Qualcomm.
1 TNC RF
1 RJ-45
TNC RF: Omni antenna, supporting GPRS/EDGE/UMTS/HSDPA.
RJ-45: RS-232
