Interface specifications
Table 28 Interface specifications
Item
Connector
Number of connectors
Interface rate
Interface standard
Cable
Supported service
Maximum received and sent frame
Interface LEDs
Figure 22 SIC-1ADSL panel
Table 29 LED description
LED
LINK
ACT
Interface cables and the connection methods
For more information about ADSL interface cables and the connection methods, see
"ADSL/BS/FXS/FXO/AM/FCM
Description
RJ-11
1
•
•
•
•
•
•
•
•
Telephone cable
ADSL over the regular telephone line
1700 bytes
Description
•
Off: The loop is inactive.
•
On: The loop has been activated and has entered the data mode
•
Flashing: The loop is being activated.
•
Off: No data is being transmitted or received.
•
Flashing: Data is being received or/and transmitted.
interface."
In ADSL full rate mode (ITU-T 992.1 G.DMT/ANSI T1.413):
8 Mbps (downlink rate)
1024 kbps (uplink rate)
In ADSL Lite mode (ITU-T 992.2 G.Lite):
64 kbps to 1 Mbps (downlink rate)
64 kbps to 512 kbps (uplink rate)
In ADSL2+ full rate mode (ITU-T 992.5):
24 Mbps (downlink rate)
1024 kbps (uplink rate)
ITU-T 992.1 G.DMT
ITU-T 992.2 G.Lite
ANSI T1.413 Issue 2
ITU-T 992.3
ITU-T 992.5
